Description
This pump is a SPE625S250-1 with a 6-inch NPT connection and operates at 3600 rpm.
Specifications
Manufacturer | Grundfos |
---|---|
Part Number | 92673235 |
Pump speed on which pump data are based | 3600 rpm |
Rated flow | 656 US gpm |
Rated head | 105 ft |
Stages | 1 |
Number of reduced-diameter impellers | NONE |
Shaft seal for motor | SiC/SiC NBR |
Approvals | CULDWUS,CCSAUS |
Approvals for drinking water | PROP65 |
Curve tolerance | ISO9906:2012 3B |
Motor version | T60 |
Return valve | YES |
Pump | Stainless steel, EN 1.4301, AISI 304 |
Impeller | Stainless steel, EN 1.4301, AISI 304 |
Motor | Stainless steel, EN 1.4301, AISI 304 |
Maximum operating pressure | 870.23 psi |
Maximum outlet pressure | 66.72 psi |
Type of connection | NPT(F) |
Size of connection | 6 inch |
Motor diameter | 6 inch |
Pumped liquid | Water |
Liquid temperature range | 5 .. 140 °F |
Selected liquid temperature | 68 °F |
Density | 62.29 lb/ft³ |
Motor type | PM |
Motor flange design | Grundfos |
Rated power - P2 | 25 HP |
Power (P2) required by pump | 24.8 HP |
Main frequency | 60 Hz |
Rated voltage | 3 x 410-480 V |
Motor frequency | 120 Hz |
Service factor | 1.15 |
Rated current | 34.2 A |
Rated speed | 1650-3600 rpm |
Motor efficiency at full load | 93 % |
Number of poles | 4 |
Start. method | Direct-on-line (DOL) |
Enclosure class (IEC 34-5) | IP68 |
Insulation class (IEC 85) | F |
Built-in motor protection | NONE |
Thermal protec | external |
Built-in temperature transmitter | No |
Number of cables | 1 |
Windings | Enamelled |
Rpm related to frequency | 3600 rpm at 120 Hz |
Frequency converter | VFD IPM type required |
Net weight | 186 lb |
Gross weight | 265 lb |
Shipping volume | 22.5 ft³ |
Sales region | Namreg |
Country of origin | US |
Custom tariff no. | 8413.70.21 |
Recommended CUE (IP20) | 99619019 |
Recommended Sine wave filter (IP20) | 92617587 |
