Grundfos 84Z04002, 3/4HP Baldor Motor 208-230/460V TEFC

Roll over image to zoom in Click on image to zoom

This motor is a Baldor 56C model with a power rating of 0.75 horsepower, suitable for use in three-phase systems operating at 208-230/460 volts. It has a Totally Enclosed Fan Cooled (TEFC) design, which helps protect the motor from external elements and enhances its durability in various applications.

Manufacturer	Grundfos
Part Number	84Z04002
Shaft diameter	0.63 in
Length of shaft end	1.88 in
Approvals for motor	cURus/cCSAus
Energy approvals for motor	CC,
Cooling	TEFC
Maximum ambient temperature	104 °F
Flange size for motor	56C
Motor type	BALDOR
Rated power - P2	0.75 HP
Main frequency	60 Hz
Rated voltage	3 x 208-230/460 V
Service factor	1.25
Rated current	3,10-2,60/1,30 A
Full load SF current	3,1-3,0/1,5 A
Rated speed	3450 rpm
IE efficiency	IE2 74,0%
IE Efficiency class	IE2 / NEMA Energy
Motor efficiency at full load	74.0 %
Number of poles	2
Enclosure class (IEC 34-5)	TEFC
Insulation class (IEC 85)	B
Built-in motor protection	NONE
Tropic protec	No
Mounting design per IEC 34-7	NEMA type C
Bearing insulation type N-end	Steel Bearing
Net weight	18.6 lb
Color/Type	BLACK
Custom tariff no.	8501.51.4040

Baldor motors (I & O instructions)

WEG motors, GB/ES version (I & O instructions)

WEG motors, Additional languages (I & O instructions)
