This close-coupled in-line pump has an in-line design with 2-inch suction and discharge ports aligned to reduce system piping strain. The assembly includes a cast iron casing and bracket paired with a 7.9-inch diameter stainless steel impeller and shaft. This self-supporting configuration allows for installation in either horizontal or vertical orientations without external strapping. The hydraulic structure is built to Hydraulic Institute standards, accommodating operating pressures up to 175 PSI. A mechanical seal with a silicon carbide stationary seat, carbon rotating element, and Viton elastomer is included to manage fluid temperatures up to 250°F, while integrated pressure tappings allow for differential readings across the pump casing.
The unit is equipped with a 3 HP, 1750 RPM, ODP motor configured for 208-230/460V, 3PH power supply. Maintenance-free operation is supported by permanently sealed, grease-lubricated motor ball bearings. Utilizing a rear pull-out design, the assembly permits complete removal of the motor and rotating components for servicing without disturbing the connected piping layout.
