This motor is a Baldor 213TC with a power rating of 7.5 HP and operates on a voltage range of 208-230. It has a Totally Enclosed Fan Cooled (TEFC) design, making it suitable for various standard motor applications.
Specifications
Manufacturer
Grundfos
Part Number
85700017
Shaft diameter
1.37 in
Length of shaft end
3.13 in
Approvals for motor
cURus/cCSAus
Energy approvals for motor
CC,
Cooling
TEFC
Maximum ambient temperature
104 °F
Flange size for motor
213TC
Motor type
BALDOR
Rated power - P2
7.5 HP
Main frequency
60 Hz
Rated voltage
1 x 208-230 V
Service factor
1.15
Rated current
33.8-31.0 A
Full load SF current
39.3-35.5 A
Rated speed
3450 rpm
IE efficiency
82%
Motor efficiency at full load
82 %
Number of poles
2
Enclosure class (IEC 34-5)
TEFC
Insulation class (IEC 85)
F
Built-in motor protection
NONE
Tropic protec
No
Bearing insulation type N-end
Steel Bearing
Net weight
114 lb
Color/Type
BLACK
