Description
This vertical multistage centrifugal pump has suction and discharge ports on the same level.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 99163453 |
| Rated pump speed | 2917 rpm |
| Rated flow | 25.5 US gpm |
| Rated head | 493.5 ft |
| Maximum head | 648 ft |
| Actual impeller diameter | 2.88 in |
| Stages | 29 |
| Impellers | 29 |
| Number of reduced-diameter impellers | 0 |
| Low NPSH | Y |
| Pump orientation | Vertical |
| Shaft seal arrangement | Single |
| Code for shaft seal | HQQE |
| Approvals | CE,EAC,UKCA,CURUS,SEPRO |
| Approvals for drinking water | WRAS,ACS |
| Curve tolerance | ISO9906:2012 3B |
| Pump version | K |
| Base | Cast iron, EN 1561 EN-GJL-200, ASTM A48-25B |
| Impeller | Stainless steel, EN 1.4301, AISI 304 |
| Material code | A |
| Code for rubber | E |
| Maximum ambient temperature | 140 °F |
| Maximum operating pressure | 362.59 psi |
| Max pressure at stated temperature | 363 psi / 250 °F, 363 psi / -4 °F |
| Type of connection | DIN / ANSI / JIS |
| Size of inlet connection | DN 25/32 |
| Size of outlet connection | DN 25/32 |
| Pressure rating for connection | PN 25 |
| Flange rating inlet | 250 lb |
| Flange size for motor | FT130 |
| Connect code | FGJ |
| Pumped liquid | Water |
| Liquid temperature range | -4 .. 248 °F |
| Selected liquid temperature | 68 °F |
| Density | 62.29 lb/ft³ |
| Motor standard | IEC |
| Motor type | 112CA |
| Rated power - P2 | 5.5 HP |
| Power (P2) required by pump | 5.5 HP |
| Main frequency | 50 Hz |
| Rated voltage | 3 x 220-240D/380-415Y V |
| Service factor | 1.15 |
| Rated current | 13.6/7.90 A |
| Starting current | 1000-1110 % |
| Cos phi - power factor | 0.87 |
| Rated speed | 2920-2940 rpm |
| IE Efficiency class | IE3 |
| Motor efficiency at full load | 88.1 % |
| Motor efficiency at 3/4 load | 88.6-88.2 % |
| Motor efficiency at 1/2 load | 85.2-88.1 % |
| Number of poles | 2 |
| Enclosure class (IEC 34-5) | 55 Dust/Jetting |
| Insulation class (IEC 85) | F |
| Built-in motor protection | PTC |
| Frequency converter | None |
| Pressure sensor | N |
| Minimum efficiency index, MEI ≥ | 0.57 |
| DOE Pump Energy Index CL | 0.94 |
| Net weight | 155 lb |
| Gross weight | 201 lb |
| Shipping volume | 9.08 ft³ |
