This motor is a Baldor 56C model with a power rating of 1.5 HP and operates on 115/208-230 volts. It has a Totally Enclosed Fan Cooled (TEFC) design, suitable for various standard motor applications.
Specifications
Manufacturer
Grundfos
Part Number
84Z04007
Shaft diameter
0.63 in
Length of shaft end
1.88 in
Approvals for motor
cURus/cCSAus
Energy approvals for motor
CC,
Cooling
TEFC
Maximum ambient temperature
104 °F
Flange size for motor
56C
Motor type
BALDOR
Rated power - P2
1.5 HP
Main frequency
60 Hz
Rated voltage
1 x 115/208-230 V
Service factor
1.30
Rated current
17/9,50-8,60 A
Full load SF current
20,4/11,3-10,2 A
Rated speed
3450 rpm
IE efficiency
71%
Motor efficiency at full load
71 %
Number of poles
2
Enclosure class (IEC 34-5)
TEFC
Insulation class (IEC 85)
B
Built-in motor protection
NONE
Tropic protec
No
Thermal protec
internal
Bearing insulation type N-end
Steel Bearing
Net weight
42.5 lb
Color/Type
BLACK
Country of origin
US
Custom tariff no.
8501.40.5040
