Description
This is a compact, encapsulated stainless steel pump, featuring motor units enclosed in a pressure sleeve for low noise and reduced maintenance. Hermetically sealed for durability, these pumps are suitable for industrial filtration and domestic water supply applications.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 98490820 |
| Rated flow | 88.1 US gpm |
| Rated head | 226.4 ft |
| Stages | 6 |
| Curve tolerance | ISO9906:2012 3B |
| Pump | Stainless steel, DIN W.-Nr. 1.4301, AISI 304 |
| Impeller | Stainless steel, EN 1.4301, AISI 304 |
| Motor | Stainless steel, EN 1.4301, AISI 304 |
| Code for rubber | NBR |
| Sleeve | Stainless steel, AISI 304, EN 1.4301 |
| Maximum operating pressure | 1199.46 psi |
| Maximum permissible inlet pressure | 725.19 psi |
| Maximum outlet pressure | 1189.31 psi |
| Pipe connection standard | PJE |
| Pipe connection | 89 mm |
| Pumped liquid | Water |
| Maximum liquid temperature | 104 °F |
| Selected liquid temperature | 68 °F |
| Density | 62.29 lb/ft³ |
| Rated power - P2 | 7.5 HP |
| Main frequency | 60 Hz |
| Rated voltage | 3 x 440-460-480 V |
| Service factor | 1.15 |
| Rated current | 11.4-11.7-12.1 A |
| Starting current | 560-580-590 % |
| Cos phi - power factor | 0.84-0.79-0.73 |
| Start. method | Direct-on-line (DOL) |
| Enclosure class (IEC 34-5) | IP66 |
| Thermal protection | External |
| Built-in temperature transmitter | Yes |
| Minimum efficiency index, MEI ≥ | 0.70 |
| Net weight | 139 lb |
| Gross weight | 197 lb |
| Shipping volume | 11.3 ft³ |
