Acid capacity [g] |
0.85 g |
Acid capacity [oz] |
0.03 oz |
Activated alum/Molec sieve [%] |
20% / 80% |
Activated alumina [%] |
20% |
Approval |
UL |
Body material |
Steel |
Braket |
No |
Brand |
ELIMINATOR |
China RoHS compliance |
Yes exceed limitations |
Connection material |
Steel |
Core |
Solid core |
Core Size code |
05 cu.in. |
Core type |
Solid core |
Drying Cap[Drops of Water]24°C |
R134a: 122, R290: --, R32: 102, R404A: 127, R407C: 118, R410A: 110, R507: 133 |
Drying Cap[Drops of Water]52°C |
R134a: 111, R290: --, R32: 94, R404A: 120, R407C: 109, R410A: 98, R507: 119 |
EU RoHS compliance |
Yes with exemptions |
EU RoHS exemption clause |
6(a) |
Filter application |
Std Moisture & Acid Capacity |
Flow capacity [kW] |
R134a: 16.0, R290: --, R32: 24.3, R404A: 11.2, R407C: 16.3, R410A: 16.6, R507: 10.9 |
Flow capacity [TR] |
R134a: 4.5, R290: --, R32: 6.9, R404A: 3.2, R407C: 4.6, R410A: 4.7, R507: 3.1 |
Flow direction indicator |
Label printed 1-way arrow |
Fluid Group |
2 |
In scope of WEEE and contain batteries |
No |
Inlet 1 connection size [in] |
3/8 in |
Inlet connection type |
Face seal |
LiqCap Cond (ARI 710-2009)[SI] |
Delta p=0.07bar, tliq= 30°C, tvap=-15°C |
LiqCapCond (ARI 710-2009)[IMP] |
Delta p=1psi, tliq= 86°F, tvap=5°F |
Lubricants compatibility |
Oil-free applications |
Max. Working Pressure [bar] |
46 bar |
Max. Working Pressure [psig] |
667 psig |
Molecular sieve [%] |
80% |
Net volume [foz US] |
2.88 Fluid Ounce US |
Net volume [l] |
0.085 L |
Oil-free refrigerants |
R1234ze(E), R134a, R513A, R515A |
Outlet 1 connection size [in] |
3/8 in |
Outlet connection type |
Face seal |
REACH Candidate List substances |
No |
Refrigerants |
R1233zd(E), R1234yf, R1234ze(E), R125, R134a, R22/R407C, R23, R290, R32, R404A, R407A, R407F, R407H, R410A, R422B, R422D, R438A, R444B, R448A, R449A, R449B, R450A, R452A, R452B, R454A, R454B, R454C, R455A, R463A, R507A, R513A, R515B, R516A, R600 |
Serviceable |
No |
Shell volume [foz US] |
4.12 Fluid Ounce US |
Shell volume [l] |
0.12 L |
Solid core surface [cm2] |
82 cm² |
Solid core surface [in2] |
12.72 in² |
Solid core volume [cm3] |
37 cm³ |
Solid core volume [in3] |
2.25 in³ |
Temperature range [°C] [max] |
70°C |
Temperature range [°C] [min] |
-40°C |
Temperature range [°F] [max] |
160°F |
Temperature range [°F] [min] |
-40°F |
Type |
DCL |
Type designation |
DCL 053FS |
UK RoHS compliance |
Out of scope |
UL approval file name |
SA6398 |
UL approved refrigerants |
R125, R134a, R22, R23, R404A, R407A, R407C, R407F, R410A, R422B, R422D, R438A, R448A, R449A, R449B, R450A, R452A, R507A, R513A |
