NIBCO T-585-S6R-66-LL 1-1/4" FIPT Stainless Steel Ball Valve NL95X0B

SKU: LSIE3KABN3 Part Number: NL95X0B Model: T-585-S6R-66-LL

Price:
Sale price$159.95 Regular price$318.40

Save 50% Call 844-448-0880 for large volume pricing

Stock:
Typically Stocked - Call or Chat to confirm
 More payment options

Description

This NIBCO stainless steel ball valve provides bubble-tight shutoff at 1000 psi. The two-piece valve may be used on hot/cold water, HVAC, and is recommended for process piping, some chemical and utility service applications. This valve features a standard lockable lever handle for security and a cast mounting pad for actuation purposes. It may be used for isolation and throttling (half open to full open only). This NIBCO ball valve provides ease of operation with quarter-turn (90°) open to close. The reinforced PTFE seat ring and stainless steel ball/stem exhibits high chemical resistance properties and is recommended for process piping. This valve features threaded ends for easy installation. Please refer to NIBCO technical data sheets, valve selection guides, chemical resistance guide and catalog for engineering and installation information. Choose NIBCO ball valves for the most specified, versatile and economical valve option in commercial and industrial applications. NIBCO ball valves are backed by the exclusive NIBCO INC. 5-year 125% limited warranty.

Features

  • Valve pressure rating 1,000 psi 69 bar non-shock cold working pressure
  • Maximum temperature rating 400°F
  • Full port
  • Blowout-proof stem
  • Stainless steel ball and stem
  • Cast ISO mounting pad
  • Vented ball
  • Locking lever handle
  • Threaded end connections
  • Conforms to MSS SP-110

Specifications

Manufacturer NIBCO
Part Number NL95X0B
Model T-585-S6R-66-LL
Series T-585-S6-R-66-LL
Type of Valve Ball
Nominal Pipe Size 1-1/4"
End Connection Type T -- Female NPT Thread (FIPT)
Material Stainless Steel
Ball Body Type Two-Piece
Ball Operator CS Locking Lever Handle
Ball Port Style Full Port
Ball Stem Material SS - Stainless Steel
Trim Package Stainless Steel Trim
Seat Seal Material RPTFE (Reinforced)
Turns Operations Quarter-Turn
Pressure Rating (CWP) 1000 psi/69 Bar CWP
Potable Water Code LL Compliant not used potable
UPC Code 039923797896
Length 9.35"
Width 4.78"
Height 2.44"
Country of Origin TW

About NIBCO

NIBCO is a recognized manufacturer and brand leader of valves, fittings, and flow-control products.
