This motor is identified as an MTR2 TEF .33H with a 1X115/230 voltage and operates at 60Hz. It is categorized under standard motors and associated with the Baldor 56C designation.
Specifications
Manufacturer
Grundfos
Part Number
85680001
Shaft diameter
0.63 in
Length of shaft end
1.88 in
Approvals for motor
cURus/cCSAus
Energy approvals for motor
CC,
Cooling
TEFC
Maximum ambient temperature
104 °F
Flange size for motor
56C
Motor type
BALDOR
Rated power - P2
0.33 HP
Main frequency
60 Hz
Rated voltage
1 x 115/230 V
Service factor
1.35
Rated current
6.00/3.00 A
Full load SF current
6.8/3.4 A
Rated speed
3450 rpm
IE efficiency
58%
Motor efficiency at full load
58 %
Number of poles
2
Enclosure class (IEC 34-5)
TEFC
Insulation class (IEC 85)
B
Thermal protec
internal
Bearing insulation type N-end
Steel Bearing
Net weight
18.3 lb
Color/Type
BLACK
