Description
This horizontal end-suction pump is reliable, quiet, and compact with a modular design that allows for customized solutions. It is available in cast iron and stainless steel.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 99218164 |
| Pump speed on which pump data are based | 2900 rpm |
| Rated flow | 13.6 US gpm |
| Rated head | 96.04 ft |
| Impellers | 3 |
| Code for shaft seal | AVBV |
| Approvals | CE,CULUS,EAC,CURUS,UKCA |
| Approvals for drinking water | ACS,NSF61,UBA |
| Curve tolerance | ISO9906:2012 3B |
| Pump version | A |
| Pump housing | Stainless steel, EN 1.4401, AISI 316 |
| Impeller | Stainless steel, EN 1.4401, AISI 316 |
| Material code | G |
| Code for rubber | V |
| Range of ambient temperature | -4 .. 131 °F |
| Maximum operating pressure | 145.04 psi |
| Max pressure at stated temperature | 145 psi / 104 °F, 90 psi / 194 °F |
| Type of connection | NPT(F) |
| Size of suction port | 1 inch |
| Size of outlet port | 1 inch |
| Connect code | S |
| Pumped liquid | Water |
| Liquid temperature range | -4 .. 194 °F |
| Selected liquid temperature | 68 °F |
| Density | 62.29 lb/ft³ |
| Motor standard | NEMA |
| Frame size | 71BA |
| Rated power - P2 | 0.577 HP |
| Main frequency | 50 Hz |
| Suitable for 50/60 Hz (Yes/No) | Y |
| Rated voltage | 3 x 380-415 V V |
| Service factor | 1.00 |
| Rated current | 1.4-1.5 A |
| Starting current | 550-600 % |
| Rated speed | 2860-2890 rpm |
| Enclosure class (IEC 34-5) | IP55 |
| Insulation class (IEC 85) | F |
| Built-in motor protection | NONE |
| Cable included (Yes/No) | N |
| Frequency converter | None |
| Terminal box position | 12 |
| Minimum efficiency index, MEI ≥ | 0.7 |
| Net weight | 27.4 lb |
| Gross weight | 32.9 lb |
