This motor is a NEMA 56C type with a power rating of 0.33 HP and operates on 115/208-230V. It has a Totally Enclosed Fan Cooled (TEFC) design, suitable for various standard applications.
Specifications
Manufacturer
Grundfos
Part Number
84654601
Shaft diameter
0.62 in
Length of shaft end
1.93 in
Approvals for motor
cURus/cCSAus
Energy approvals for motor
CC,
Cooling
TEFC
Range of ambient temperature
-22 .. 104 °F
Flange size for motor
56C
Motor type
BALDOR
Rated power - P2
0.33 HP
Main frequency
60 Hz
Rated voltage
1 x 115/230 V
Service factor
1.35
Rated current
6/3 A
Full load SF current
6.8/3.4 A
Rated speed
1725 rpm
Motor efficiency at full load
60 %
Number of poles
4
Enclosure class (IEC 34-5)
TEFC
Insulation class (IEC 85)
B
Built-in motor protection
NONE
Mounting design per IEC 34-7
NEMA type C
Bearing insulation type N-end
Steel Bearing
Net weight
19.8 lb
Color/Type
BLACK
