NIBCO TC-580-CSR-25-LL 2" FIPT Carbon Steel Ball Valve NL94T0D

SKU: LSII031N94 Part Number: NL94T0D Model: TC-580-CSR-25-LL

Price:
Sale price$237.95 Regular price$474.50

Save 50% Call 844-448-0880 for large volume pricing

Stock:
Typically Stocked - Call or Chat to confirm
 More payment options

Description

This NIBCO carbon steel ball valve provides bubble-tight shutoff at 2000 psi. This valve features a lockable lever handle for security and a cast mounting pad for actuation purposes. It may be used for isolation and throttling (half open to full open only). The two-piece valve may be used on hot/cold water, HVAC, and is recommended for process piping, some chemical and utility service applications. This NIBCO carbon steel ball valve provides ease of operation with quarter-turn (90°) open to close. The reinforced PTFE seat ring and stainless steel ball exhibits high chemical resistance properties and is recommended for process piping. This valve features threaded ends for easy installation. Please refer to NIBCO technical data sheets, valve selection guides, chemical resistance guide and catalog for engineering and installation information. Choose NIBCO ball valves for the most specified, versatile and economical valve option in commercial and industrial applications. NIBCO ball valves are backed by the NIBCO INC. 5-year 125% limited warranty.

Features

  • Valve pressure rating 2000 psi 138 bar non-shock cold working pressure
  • Maximum temperature rating 400°F
  • Conventional port
  • Blowout-proof stem
  • Stainless steel ball and carbon steel stem
  • Cast ISO mounting pad
  • Vented ball
  • Locking lever handle
  • Threaded end connections
  • Conforms to MSS SP-110

Specifications

Manufacturer NIBCO
Part Number NL94T0D
Model TC-580-CSR-25-LL
Series TC-580-CS-R-25-LL
Type of Valve Ball
Nominal Pipe Size 2"
End Connection Type T -- Female NPT Thread (FIPT)
Material Carbon Steel
Ball Body Type Two-Piece
Ball Operator CS Locking Lever Handle
Ball Port Style Conventional Port
Ball Stem Material SS/CS - Stainless Steel and Carbon Steel
Seat Seal Material RPTFE (Reinforced)
Turns Operations Quarter-Turn
Pressure Rating (CWP) 2000 psi/138 Bar CWP
Potable Water Code LL Compliant not used potable
UPC Code 039923678461
Length 9.92"
Width 4.77"
Height 3.19"
Country of Origin TW

About NIBCO

NIBCO is a recognized manufacturer and brand leader of valves, fittings, and flow-control products.
