Grundfos 96523199, CRI10-9 A-FGJ-A-E-HQQE Vertical Multistage Pump

SKU: LSII15UGZS Part Number: 96523199

Price:
Sale price$5,794.95 Regular price$8,649.00

Save 33% Call 844-448-0880 for large volume pricing

Stock:
Call or Chat for availability
 More payment options

Description

This vertical multistage centrifugal pump has suction and discharge ports on the same level. It is constructed with stainless steel materials in contact with the liquid, suitable for applications such as water treatment fertigation, chemigation, dosing, controls and digital groundwater management, and drip irrigation systems.

Specifications

Manufacturer Grundfos
Part Number 96523199
Rated pump speed 3467 rpm
Rated flow 53.3 US gpm
Rated head 341.6 ft
Maximum head 433.1 ft
Actual impeller diameter 3.66 in
Stages 9
Impellers 9
Number of reduced-diameter impellers 0
Low NPSH N
Pump orientation Vertical
Shaft seal arrangement Single
Code for shaft seal HQQE
Approvals CURUS
Approvals for drinking water NSF/ANSI 61
Curve tolerance ISO9906:2012 3B
Pump version A
Cooling TEFC
Base Stainless steel, EN 1.4408, AISI 316
Impeller Stainless steel, EN 1.4301, AISI 304
Material code A
Code for rubber E
Bearing SIC
Maximum ambient temperature 140 °F
Maximum operating pressure 232.06 psi
Max pressure at stated temperature 232 psi / 250 °F, 232 psi / -4 °F
Type of connection DIN / ANSI / JIS
Size of inlet connection DN 50
Size of outlet connection DN 50
Pressure rating for connection PN 25
Flange rating inlet 300 lb
Flange size for motor 213TC
Connect code FGJ
Pumped liquid Water
Liquid temperature range -4 .. 248 °F
Selected liquid temperature 68 °F
Density 62.29 lb/ft³
Motor standard NEMA
Motor type 132DA
Rated power - P2 7.5 HP
Power (P2) required by pump 7.5 HP
Main frequency 60 Hz
Rated voltage 3 x 208-230YY/460Y V
Service factor 1.15
Rated current 19,5-18,1/9,09 A
Starting current 1020-1480 %
Full load SF current 22,4-20,8/10,4 A
Cos phi - power factor 0.89-0.86
Rated speed 3490-3520 rpm
IE Efficiency class NEMA Premium / IE3 60Hz
Motor efficiency at full load 89.5 %
Motor efficiency at 3/4 load 89.6-89.1 %
Motor efficiency at 1/2 load 88.1-86.7 %
Number of poles 2
Enclosure class (IEC 34-5) 55 Dust/Jetting
Insulation class (IEC 85) F
Built-in motor protection PTC
Frequency converter None
DOE Pump Energy Index CL 0.87
Net weight 194 lb
Gross weight 214 lb
Shipping volume 10.1 ft³

About Grundfos

Grundfos has a wide range of products, pump solutions, and services for all applications. Grundfos' energy-efficient pumps provide comfort and move water, wastewater, and industrial liquids all over the world.
