Description
This motor is a WEG 56C model with a 3x230/460 voltage configuration, 4-pole design, and a power rating of 1.5 horsepower. It has a Totally Enclosed Fan Cooled (TEFC) construction suitable for various standard applications.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 99887796 |
| Shaft diameter | 0.62 in |
| Length of shaft end | 1.88 in |
| Approvals for motor | cURus/cCSAus |
| Exp. approval | NEC Ex |
| Energy approvals for motor | CC |
| Explosion approval NEC | Y |
| Explosion approval by | UL |
| Explosion approval grade | Class I Division 1 |
| Cooling | IC 411 |
| Cable gland entry | Knock out |
| Range of ambient temperature | -4 .. 104 °F |
| Flange size for motor | 56C |
| Motor type | WEG |
| Rated power - P2 | 1.5 HP |
| Main frequency | 60 Hz |
| Rated voltage | 3 x 208-230/460 V |
| Service factor | 1.00 |
| Rated current | 4,67-4,2/2,1 A |
| Maximum current consumption | 4,67-4,2/2,11 A |
| Starting current | 750 % |
| Full load SF current | 4.2/2.11 A |
| Cos phi - power factor | 0.76 |
| Rated speed | 1725 rpm |
| Rated full-load torque | 6.2 Nm |
| Locked-rotor torque | 280 % |
| Breakdown torque | 345 % |
| Moment of inertia | 0.123 lb ft² |
| IE efficiency | IE3 86,5% |
| IE Efficiency class | IE3 / NEMA Premium |
| Motor efficiency at full load | 86.5 % |
| Motor efficiency at 3/4 load | 86 % |
| Motor efficiency at 1/2 load | 83.4 % |
| Number of poles | 4 |
| Enclosure class (IEC 34-5) | TEFC |
| Insulation class (IEC 85) | F |
| Built-in motor protection | NONE |
| Tropic protec | No |
| Thermal protec | None |
| R1 | 4.78 ohm |
| R2 | 4.78 ohm |
| R3 | 4.78 ohm |
| Winding 1 | PHASE 1 |
| Winding 2 | PHASE 2 |
| Winding 3 | PHASE 3 |
| Mounting design per IEC 34-7 | Nema assembly W-6 |
| Cos phi 1/2 | 0.61 |
| Cos phi 3/4 | 0.71 |
| Bearing insulation type N-end | N |
| Net weight | 38.6 lb |
| Color/Type | RAL 9005 |
| Country of origin | US |
| Custom tariff no. | 8501.52.8040 |
