This motor is a Baldor 364TSC with a power rating of 60 horsepower, operating at 230/460 volts. It is classified as a Type C motor.
Specifications
Manufacturer
Grundfos
Part Number
84Z03818
Shaft diameter
1.87 in
Length of shaft end
3.75 in
Approvals for motor
cURus/cCSAus
Energy approvals for motor
CC,
Cooling
TEFC
Maximum ambient temperature
122 °F
Flange size for motor
364TSC
Motor type
BALDOR
Rated power - P2
60 HP
Main frequency
60 Hz
Rated voltage
3 x 230/460 V
Service factor
1.15
Rated current
132/66 A
Full load SF current
75 A
Cos phi - power factor
0.87
Rated speed
3550 rpm
Moment of inertia
5.316 lb ft²
IE efficiency
IE3 93,6%
IE Efficiency class
IE3 / NEMA Premium
Motor efficiency at full load
93.6 %
Number of poles
2
Enclosure class (IEC 34-5)
TEFC
Insulation class (IEC 85)
F
Built-in motor protection
NONE
Tropic protec
No
Thermal protec
external
Mounting design per IEC 34-7
NEMA type C
Bearing insulation type N-end
Steel Bearing
Net weight
606 lb
Color/Type
BLACK
Country of origin
US
Custom tariff no.
8413.70.2040
