Description
This submersible pump is a multi-stage, speed-regulated device designed for raw water supply, groundwater lowering, and pressure boosting. It is constructed entirely of stainless steel DIN W.-Nr. EN 1.4301 and can be installed both horizontally and vertically. The pump handles clean, thin, non-aggressive liquids without solid particles or fibers and includes a built-in non-return valve. Its motor is a 3-phase synchronous high-efficiency permanent magnet type requiring a frequency drive for operation and speed regulation.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 92673196 |
| Pump speed on which pump data are based | 3600 rpm |
| Rated flow | 88.1 US gpm |
| Rated head | 1818 ft |
| Stages | 40 |
| Number of reduced-diameter impellers | NONE |
| Shaft seal for motor | SiC/SiC NBR |
| Approvals | CCSAUS |
| Approvals for drinking water | PROP65 |
| Curve tolerance | ISO9906:2012 3B |
| Motor version | T60 |
| Return valve | YES |
| Pump | Stainless steel, EN 1.4301, AISI 304 |
| Impeller | Stainless steel, EN 1.4301, AISI 304 |
| Motor | Stainless steel, EN 1.4301, AISI 304 |
| Maximum operating pressure | 870.23 psi |
| Maximum outlet pressure | 989.16 psi |
| Type of connection | NPT(M) |
| Size of connection | 3 inch |
| Motor diameter | 6 inch |
| Minimum borehole diameter | 7.09 in |
| Pumped liquid | Water |
| Liquid temperature range | 5 .. 140 °F |
| Selected liquid temperature | 68 °F |
| Density | 62.29 lb/ft³ |
| Motor type | PM |
| Motor flange design | Grundfos |
| Rated power - P2 | 50 HP |
| Power (P2) required by pump | 49.6 HP |
| Main frequency | 60 Hz |
| Rated voltage | 3 x 410-480 V |
| Motor frequency | 120 Hz |
| Service factor | 1.15 |
| Rated current | 72.6 A |
| Rated speed | 1650-3600 rpm |
| Motor efficiency at full load | 92.4 % |
| Number of poles | 4 |
| Start. method | Direct-on-line (DOL) |
| Enclosure class (IEC 34-5) | IP68 |
| Insulation class (IEC 85) | F |
| Built-in motor protection | NONE |
| Thermal protec | external |
| Built-in temperature transmitter | No |
| Number of cables | 2 |
| Windings | Enamelled |
| Rpm related to frequency | 3600 rpm at 120 Hz |
| Frequency converter | VFD IPM type required |
| DOE Pump Energy Index CL | 0.85 |
| Net weight | 373 lb |
| Gross weight | 516 lb |
| Shipping volume | 17.5 ft³ |
| Sales region | Namreg |
| Recommended CUE (IP20) | 99619023 |
| Recommended Sine wave filter (IP20) | 92617591 |
