Grundfos 96083471, CRI3-3 A-CA-A-V-HQQV Vertical Multistage Pump

Roll over image to zoom in Click on image to zoom

Grundfos 96083471, CRI3-3 A-CA-A-V-HQQV Vertical Multistage Pump

Name: Grundfos 96083471, CRI3-3 A-CA-A-V-HQQV Vertical Multistage Pump
Brand: Grundfos
SKU: LSIN9EOTJ9
Price: 1731.95 USD
Availability: OutOfStock

SKU: LSIN9EOTJ9 Part Number: 96083471

Price:

$1,731.95 $2,585.00

Save 33% Call 844-448-0880 for large volume pricing

Stock:

Obsolete

Quantity:

This vertical multistage centrifugal pump has suction and discharge ports on the same level, with materials in contact with the liquid made from stainless steel (EN 1.4301). It is suitable for applications such as water treatment fertigation, chemigation and dosing, controls and digital groundwater management, and drip, micro spray, and soaker hose irrigation.

Manufacturer	Grundfos
Part Number	96083471
Rated pump speed	3443 rpm
Rated flow	15.4 US gpm
Rated head	67.26 ft
Maximum head	92.2 ft
Stages	3
Impellers	3
Number of reduced-diameter impellers	0
Low NPSH	N
Pump orientation	Vertical
Shaft seal arrangement	Single
Code for shaft seal	HQQV
Approvals	CURUS
Curve tolerance	ISO9906:2012 3B
Pump version	A
Cooling	TEFC
Base	Stainless steel, EN 1.4408, AISI 316
Impeller	Stainless steel, EN 1.4301, AISI 304
Material code	A
Code for rubber	V
Bearing	SIC
Maximum ambient temperature	104 °F
Maximum operating pressure	362.59 psi
Max pressure at stated temperature	363 psi / 194 °F, 363 psi / -4 °F
Type of connection	FlexiClamp
Size of inlet connection	DN 32
Size of outlet connection	DN 32
Pressure rating for connection	PN 25
Flange size for motor	56C
Connect code	CA
Pumped liquid	Water
Liquid temperature range	-4 .. 194 °F
Selected liquid temperature	68 °F
Density	62.29 lb/ft³
Motor standard	NEMA
Motor type	BALDOR
Rated power - P2	0.5 HP
Power (P2) required by pump	0.5 HP
Main frequency	60 Hz
Rated voltage	1 x 115/230 V
Service factor	1.60
Rated current	7.4/3.7 A
Full load SF current	9.8/4.9 A
Rated speed	3450 rpm
IE efficiency	62%
Motor efficiency at full load	62 %
Number of poles	2
Enclosure class (IEC 34-5)	IP54
Insulation class (IEC 85)	B
Frequency converter	None
Net weight	48.2 lb
Gross weight	59.2 lb
Shipping volume	4.94 ft³
