Grundfos 96084666, CRI5-24 A-FGJ-A-E-HQQE Vertical Multistage Pump

Roll over image to zoom in Click on image to zoom

Grundfos 96084666, CRI5-24 A-FGJ-A-E-HQQE Vertical Multistage Pump

Name: Grundfos 96084666, CRI5-24 A-FGJ-A-E-HQQE Vertical Multistage Pump
Brand: Grundfos
SKU: LSIR7RB0BB
Price: 6494.95 USD
Availability: OutOfStock

SKU: LSIR7RB0BB Part Number: 96084666

Price:

$6,494.95 $9,693.00

Save 33% Call 844-448-0880 for large volume pricing

Stock:

Obsolete

Quantity:

This vertical multistage centrifugal pump has suction and discharge ports on the same level. It is constructed with stainless steel materials (EN 1.4301) in contact with the liquid, making it suitable for applications such as water treatment fertigation, chemigation, dosing, controls and digital groundwater management, and drip or micro spray irrigation systems.

Manufacturer	Grundfos
Part Number	96084666
Rated pump speed	3508 rpm
Rated flow	30.4 US gpm
Rated head	583.7 ft
Maximum head	774.6 ft
Actual impeller diameter	2.88 in
Stages	24
Impellers	24
Number of reduced-diameter impellers	0
Low NPSH	N
Pump orientation	Vertical
Shaft seal arrangement	Single
Code for shaft seal	HQQE
Approvals	CURUS
Approvals for drinking water	NSF61
Curve tolerance	ISO9906:2012 3B
Pump version	A
Cooling	TEFC
Base	Stainless steel, EN 1.4408, AISI 316
Impeller	Stainless steel, EN 1.4301, AISI 304
Material code	A
Code for rubber	E
Bearing	SIC
Maximum ambient temperature	104 °F
Maximum operating pressure	362.59 psi
Max pressure at stated temperature	363 psi / 250 °F, 363 psi / -4 °F
Type of connection	DIN / ANSI / JIS
Size of inlet connection	DN 25/32
Size of outlet connection	DN 25/32
Pressure rating for connection	PN 25
Flange rating inlet	300 lb
Flange size for motor	213TC
Connect code	FGJ
Pumped liquid	Water
Liquid temperature range	-4 .. 248 °F
Selected liquid temperature	68 °F
Density	62.29 lb/ft³
Motor standard	NEMA
Motor type	BALDOR
Rated power - P2	7.5 HP
Power (P2) required by pump	7.5 HP
Main frequency	60 Hz
Rated voltage	1 x 208-230 V
Service factor	1.15
Rated current	33.8-31.0 A
Full load SF current	39.3-35.5 A
Rated speed	3450 rpm
IE efficiency	82%
Motor efficiency at full load	82 %
Number of poles	2
Insulation class (IEC 85)	F
Built-in motor protection	NONE
Frequency converter	None
DOE Pump Energy Index CL	0.89
Net weight	185 lb
Gross weight	297 lb
Shipping volume	12.9 ft³
