Description
This pump is a UNILIFT KP250-M-1 model with a 1/3 horsepower motor, stainless steel construction, and manual float. It operates on 115V at 60Hz and includes a 25-foot power cord for extended reach.
Specifications
Manufacturer | Grundfos |
---|---|
Part Number | 012DC201 |
Rated flow | 31.7 US gpm |
Maximum flow | 50.6 US gpm |
Rated head | 16.27 ft |
Maximum head | 26.25 ft |
Type of impeller | SEMI OPEN |
Free passage | 0.39 in |
Approvals | CCSAUS,PROP65 |
Pump housing | Stainless steel, EN 1.4301, AISI 304 |
Impeller | Stainless steel, EN 1.4301, AISI 304 |
Range of ambient temperature | 32 .. 122 °F |
Type of connection | NPT(F) |
Size of connection | 1 1/4 inch |
Maximum installation depth | 26.2 ft |
Inst dry/wet | DRY/SUBMERGED |
Liquid temperature range | 32 .. 122 °F |
Selected liquid temperature | 68 °F |
Density | 62.29 lb/ft³ |
Power input P1 | 424 W |
Main frequency | 60 Hz |
Rated voltage | 1 x 115 V |
Rated current | 4.9 A |
Starting current | 15 A |
Rated speed | 3286 rpm |
Capacitor size - run | 20 µF/250 V |
Enclosure class (IEC 34-5) | IP68 |
Insulation class (IEC 85) | F |
Built-in motor protection | CONTACT |
Thermal protec | internal |
Length of power cable | 24.9 ft |
Type of cable plug | US |
Net weight | 14.8 lb |
Gross weight | 15.7 lb |
Shipping volume | 0.44 ft³ |
Sales region | Namreg |
Country of origin | HU |
Custom tariff no. | 8413.70.2004 |
