Description
This horizontal end-suction pump is reliable, quiet, and compact with a modular design that allows for customized solutions. It is available in cast iron and stainless steel.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 97516566 |
| Pump speed on which pump data are based | 2900 rpm |
| Rated flow | 13.6 US gpm |
| Rated head | 114 ft |
| Impellers | 5 |
| Code for shaft seal | AQQE |
| Approvals | CE,EAC,UKCA |
| Approvals for drinking water | WRAS,ACS,NSF61 |
| Curve tolerance | ISO9906:2012 3B |
| Pump version | A |
| Pump housing | Cast iron, EN-GJL-200, ASTM A48-25A |
| Impeller | Stainless steel, EN 1.4301, AISI 304 |
| Material code | A |
| Code for rubber | E |
| Range of ambient temperature | -4 .. 131 °F |
| Maximum operating pressure | 145.04 psi |
| Max pressure at stated temperature | 145 psi / 194 °F, 145 psi / 194 °F |
| Type of connection | Rp |
| Size of suction port | 1 inch |
| Size of outlet port | 1 inch |
| Outlet position | 12 |
| Connect code | R |
| Pumped liquid | Water |
| Liquid temperature range | -4 .. 194 °F |
| Selected liquid temperature | 68 °F |
| Density | 62.29 lb/ft³ |
| Motor standard | IEC |
| Frame size | 71B |
| IE efficiency class | IE2 |
| Rated power - P2 | 0.805 HP |
| Main frequency | 50 Hz |
| Suitable for 50/60 Hz (Yes/No) | N |
| Rated voltage | 3 x 220-240D/380-415Y V |
| Service factor | 1.00 |
| Rated current | 2,8-3,1/1,6-1,8 A |
| Starting current | 580-500 % |
| Rated speed | 2810-2850 rpm |
| Enclosure class (IEC 34-5) | IP55 |
| Insulation class (IEC 85) | F |
| Built-in motor protection | NONE |
| Cable included (Yes/No) | N |
| Frequency converter | None |
| Terminal box position | 12 |
| Minimum efficiency index, MEI ≥ | 0.7 |
| Net weight | 27.6 lb |
| Gross weight | 33.1 lb |
| Danish VVS No. | 385212035 |
| Finnish LVI No. | 4925742 |
