This motor is a Baldor 56C model with specifications MTR2 TEF 1.5HP, 3X230D, 60HZ, and 6306 HIEF.
Specifications
Manufacturer
Grundfos
Part Number
84Z04051
Shaft diameter
0.63 in
Length of shaft end
1.87 in
Approvals for motor
cURus/cCSAus
Energy approvals for motor
CC,
Cooling
TEFC
Maximum ambient temperature
104 °F
Flange size for motor
56C
Motor type
BALDOR
Rated power - P2
1.5 HP
Main frequency
60 Hz
Rated voltage
3 x 208-230/460 V
Service factor
1.15
Rated current
4,3-4,0/2,0 A
Full load SF current
4,9-4,6/2,3 A
Rated speed
3450 rpm
IE Efficiency class
NEMA Premium / IE3 60Hz
Motor efficiency at full load
85.5 %
Number of poles
2
Enclosure class (IEC 34-5)
TEFC
Insulation class (IEC 85)
F
Built-in motor protection
NONE
Tropic protec
No
Mounting design per IEC 34-7
NEMA type C
Bearing insulation type N-end
Steel Bearing
Net weight
34 lb
Color/Type
BLACK
Custom tariff no.
8501.52.4000
