Honeywell MS81 Spring Return Direct Coupled Actuator MS8104F1210

SKU: LSITYQ5NH0 Part Number: MS8104F1210 Model: P1911872

Price:
Sale price$423.95 Regular price$709.12

Save 40% Call 844-448-0880 for large volume pricing

Stock:
In stock (6 units), ready to be shipped
 More payment options

Description

Fire and smoke actuator, spring return, 30 lb-in, 24 Vac, 2-position (SPST), 2x auxiliary switch.

MS81 Spring Return Direct Coupled Actuators (DCA) are used within heating, ventilating, and air-conditioning (HVAC) systems. They can drive a variety of quarter-turn, final control elements requiring spring return fail-safe operation.

Features & Benefits:

  • 30 lb-in or 80 lb-in minimum driving torque at 350F (176C)
  • Reversible mounting facilitates use in either clockwise (cw) or counterclockwise (ccw) spring rotation
  • Integral spring return ensures level of return torque
  • Fifteen-second spring return timing
  • No special cycling required during long-term holding. (See Operation section.)
  • No audible noise during holding
  • Patent pending design eliminates need for limit switches to reduce power consumption
  • Models available for 24, 120, and 230V AC
  • Ninety-five degree angle of rotation
  • Actuator holds rated torque at reduced power level
  • Die-cast aluminum housing
  • Housing design allows flush mounting to damper
  • Designed to operate reliably in smoke control systems requiring Underwriter's Laboratories Inc. UL555S ratings up to 350F
  • Models available with SPST position-indicating switches (7°, 85° stroke)

Certifications:

  • UL873
  • IEC 60730-1 and Part 2–14
  • UL1097 for Double Insulation
  • CE Certification Low Voltage Directive 2006/95/EC
  • CE EMC 2004/108/EC
  • C-Tick N314

Specifications

Manufacturer Honeywell
Part Number MS8104F1210
Model P1911872
