This motor is a 25HP, three-phase open drip-proof (ODP) model with a 230V delta configuration and high efficiency.
Specifications
Manufacturer
Grundfos
Part Number
84Z00H21
Approvals for motor
cURus/cCSAus
Energy approvals for motor
CC,
Cooling
ODP
Range of ambient temperature
-22 .. 104 °F
Flange size for motor
284TS
Motor type
BALDOR
Rated power - P2
25 HP
Main frequency
60 Hz
Rated voltage
3 x 230/460 V
Service factor
1.15
Rated current
56/28 A
Full load SF current
62/31 A
Rated speed
3520 rpm
IE efficiency
IE3 93%
IE Efficiency class
IE3 / NEMA Premium
Motor efficiency at full load
93 %
Number of poles
2
Enclosure class (IEC 34-5)
ODP
Built-in motor protection
NONE
Tropic protec
No
Bearing insulation type N-end
Steel Bearing
Net weight
211 lb
Color/Type
BLACK
Country of origin
US
Custom tariff no.
8501.52.4000
