Description
This DMX series includes mechanically actuated diaphragm pumps suitable for applications such as drinking water and wastewater treatment, and the pulp, paper, and textile industries.
Specifications
Manufacturer | Grundfos |
---|---|
Part Number | 99773107 |
Nominal flow rate at 60 Hz | 5.706 US gal/hour |
Number of dosing heads | 1 |
Approvals | CE,EAC,CNROHSEX,PROP65 |
Non return valve type, inlet pump 1 | Standard |
Non return valve type, outlet pump 1 | Standard |
Max viscosity | 200 mPas |
Pump housing | Thermoplastic |
Dosing head, pump 1 | Plastic, PVC |
Valve ball | Composite, PTFE |
Valve seat | Composite, PTFE |
Valve gasket | PTFE, Composite |
Max operating pressure at 60 Hz | 145.04 psi |
Maximum permissible inlet pressure | 0 psi |
Type of inlet connection | NPT(M) |
Type of outlet connection | NPT(M) |
Size of suction port | 1/2 inch |
Size of outlet port | 1/2 inch |
Pumped liquid | Water |
Liquid temperature range | 32 .. 104 °F |
Selected liquid temperature | 68 °F |
Density | 62.29 lb/ft³ |
Power input P1 | 0.121 HP |
Main frequency | 60 Hz |
Max. frequency | 60 Hz |
Rated voltage | 1 x 110/120 V |
Enclosure class (IEC 34-5) | IP65 |
Cable included (Yes/No) | N |
Power plug | US plug |
Type of connector | Type B (NEMA 5-20) |
Type of control variant | Standard |
Frequency converter | Not prepared for VFD |
Net weight | 15.4 lb |
Gross weight | 21.1 lb |
Shipping volume | 1.41 ft³ |
Diaphragm Leakage Detection | N |
Country of origin | DE |
Custom tariff no. | 8413.50.0050 |
