NIBCO T-580-CSR-66 2" FIPT Carbon Steel Ball Valve NL94GID

SKU: LSIZTSP5ER Part Number: NL94GID Model: T-580-CSR-66

Price:
Sale price$266.95 Regular price$533.00

Save 50% Call 844-448-0880 for large volume pricing

Stock:
Typically Stocked - Call or Chat to confirm
 More payment options

Description

This NIBCO bar stock carbon steel ball valve provides bubble-tight shutoff at 2000 psi (size 1/4" to 1") and 1500 psi (size 1-1/4" to 2"). The reinforced PTFE seat ring and stainless steel ball/stem exhibit high chemical resistance properties and is recommended for process piping. The two-piece valve may be used on hot/cold water, HVAC, and is recommended for process piping, some chemical and utility service applications. It may be used for isolation and throttling (half open to full open only). This valve features threaded ends for easy installation. This NIBCO carbon steel ball valve provides ease of operation with quarter-turn (90°) open to close. Please refer to NIBCO technical data sheets, valve selection guides, chemical resistance guide and catalog for engineering and installation information. Choose NIBCO ball valves for the most specified, versatile and economical valve option in commercial and industrial applications. NIBCO ball valves are backed by the exclusive NIBCO INC. 5-year 125% limited warranty.

Features

  • Valve pressure rating 2000 psi 138 bar non-shock cold working pressure (1/4" to 1")
  • Valve pressure rating 1500 psi 103 bar non-shock cold working pressure (1-1/4" to 2")
  • Maximum temperature rating 400°F
  • Conventional port
  • Blowout-proof stem
  • Stainless steel ball and stem
  • Vented ball
  • Standard lever handle
  • Threaded end connections
  • Conforms to MSS SP-110

Specifications

Manufacturer NIBCO
Part Number NL94GID
Model T-580-CSR-66
Series T-580-CS-R-66
Type of Valve Ball
Nominal Pipe Size 2"
End Connection Type T -- Female NPT Thread (FIPT)
Material Carbon Steel
Ball Body Type Two-Piece
Ball Operator CS Standard Lever Handle
Ball Port Style Conventional Port
Ball Stem Material SS - Stainless Steel
Trim Package Stainless Steel Trim
Seat Seal Material RPTFE (Reinforced)
Turns Operations Quarter-Turn
Pressure Rating (CWP) 1500 psi/103 Bar CWP
Potable Water Code Not LL Comp not intend potable
UPC Code 039923675095
Length 9.55"
Width 5.06"
Height 3.5"
Country of Origin TW

About NIBCO

NIBCO is a recognized manufacturer and brand leader of valves, fittings, and flow-control products.
