NIBCO F-609-RWS 10" Flanged Ductile Iron Gate Valve NS5031M

SKU: NBC05-1345 Part Number: NS5031M Model: F-609-RWS

Price:
Sale price$4,362.95 Regular price$8,725.00

Save 50% Call 844-448-0880 for large volume pricing

Stock:
Typically Stocked - Call or Chat to confirm
 More payment options

Description

10" flanged resilient wedge ductile iron gate valve for fire protection. It features a non-rising stem, bolted bonnet, and epoxy coated body inside and out per AWWA C-550 (coating NSF and FDA certified).

Features

  • 300 psi/20.7 bar non-shock cold working pressure
  • Non-rising stem
  • Bolted bonnet
  • Resilient wedge
  • Epoxy coated body inside and out per AWWA C-550 (coating NSF and FDA certified)
  • Class 125 flanged end connections
  • Meets or exceeds performance requirements of AWWA C509 and C515 for 3" and larger valves
  • Listed by UL/ULC (UL262)
  • FM Approved

Specifications

Manufacturer NIBCO
Part Number NS5031M
Model F-609-RWS
Valve Type Gate Valve
Application Fire Protection
Connection 10" Flanged
Material Ductile Iron
Cold Working Pressure 300 psi
Stem Design Non-Rising
Bonnet Style Bolted
Trim Material Stainless Steel
Handle Style Standard Handwheel
Turns Operations Multi-Turn
Potable Water Code LL Compliant NSF/ANSI 372
Length 31.73"
Width 16.14"
Height 13"
UPC 39923366245
Country of Origin US
CA Proposition 65 Warning Statement WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

About NIBCO

NIBCO is a recognized manufacturer and brand leader of valves, fittings, and flow-control products.
