This circulator pump is a single-speed unit with a corrosion-resistant stainless-steel housing, designed for hot-water recirculation. It provides reliable and maintenance-free operation, suitable for domestic hot water recirculation applications.
Specifications
Manufacturer
Grundfos
Part Number
98961739
Model
UP26-96SF
Speed Number
1
Max flow
28.2 US gpm
Maximum head
29.86 ft
Approvals
UL, CSA
Pump housing
Stainless steel, EN 1.4301
Impeller
Composite, PES
Maximum ambient temperature
104 °F
Ambient max at 176°F liquid
176 °F
Maximum operating pressure
145.04 psi
Type of connection
USA Oval, S.S. Flange
Pipe connection
2 - Bolt Flange
Pressure rating for connection
PN 10
Port-to-port length
6 1/2 in
Pumped liquid
Water
Liquid temperature range
35.6 .. 230 °F
Selected liquid temperature
140 °F
Density
61.35 lb/ft³
Max. power input
205 W
Main frequency
60 Hz
Rated voltage
1 x 230 V
Current in speed 3
0.8 A
Capacitor size - run
2.5 µF/380 V
Number of poles
2
Insulation class (IEC 85)
F
Built-in motor protection
CONTACT
Thermal protec
internal
Terminal box position
9H
Gross weight
11.5 lb
