This in-line pump has 1 1/2" suction and discharge connections. The unit includes a 4.75" nominal impeller and meets NSF-61 requirements. The casing, impeller, and shaft use stainless steel, while the bracket is cast iron with a stainless steel face plate. It includes a replaceable bearing cartridge assembly that isolates the bearings from system fluid temperatures. The mechanical seal assembly consists of a ceramic seat, carbon mating ring, and EPT elastomers. This unit handles fluid temperatures up to 250°F.
The pump runs with a 1/3 HP, 1750 RPM, ODP motor, configured for 115/60/1 power. Maintenance-free operation is supported by permanently sealed, grease-lubricated motor ball bearings. Utilizing a rear pull-out design, the assembly permits complete removal of the motor and rotating components for servicing without disturbing the connected piping layout.
