Grundfos 96524091, CRN20-7 A-P-A-E-HQQE Vertical Multistage Pump

Roll over image to zoom in Click on image to zoom

Grundfos 96524091, CRN20-7 A-P-A-E-HQQE Vertical Multistage Pump

Name: Grundfos 96524091, CRN20-7 A-P-A-E-HQQE Vertical Multistage Pump
Brand: Grundfos
SKU: LSIBPVNH85
Price: 9544.95 USD
Availability: OutOfStock

SKU: LSIBPVNH85 Part Number: 96524091

Price:

$9,544.95 $14,914.00

Save 36% Call 844-448-0880 for large volume pricing

Stock:

Obsolete

Quantity:

This vertical multistage centrifugal pump has suction and discharge ports on the same level, with materials in contact with the liquid made from high-grade stainless steel (EN 1.4401).

Manufacturer	Grundfos
Part Number	96524091
Rated pump speed	3497 rpm
Rated flow	111 US gpm
Rated head	389.5 ft
Maximum head	488.9 ft
Actual impeller diameter	4.13 in
Stages	7
Impellers	7
Number of reduced-diameter impellers	0
Low NPSH	N
Pump orientation	Vertical
Shaft seal arrangement	Single
Code for shaft seal	HQQE
Approvals	CURUS
Curve tolerance	ISO9906:2012 3B
Pump version	A
Cooling	TEFC
Base	Stainless steel, EN 1.4408, AISI 316
Impeller	Stainless steel, EN 1.4401, AISI 316
Material code	A
Code for rubber	E
Bearing	SIC
Maximum ambient temperature	104 °F
Maximum operating pressure	362.59 psi
Max pressure at stated temperature	363 psi / 250 °F, 363 psi / -4 °F
Type of connection	PJE
Size of inlet connection	DN 50
Size of outlet connection	DN 50
Pressure rating for connection	PN 50
Flange size for motor	254TC
Connect code	P
Pumped liquid	Water
Liquid temperature range	-4 .. 248 °F
Selected liquid temperature	68 °F
Density	62.29 lb/ft³
Motor standard	NEMA
Motor type	BALDOR
Rated power - P2	20 HP
Power (P2) required by pump	20 HP
Main frequency	60 Hz
Rated voltage	3 x 208-230/460 V
Service factor	1.15
Rated current	48-44/22 A
Full load SF current	56-50/25 A
Rated speed	3540 rpm
IE efficiency	IE3 92,4%
IE Efficiency class	IE3 / NEMA Premium
Motor efficiency at full load	92.4 %
Number of poles	2
Enclosure class (IEC 34-5)	IP54
Insulation class (IEC 85)	F
Built-in motor protection	NONE
Frequency converter	None
DOE Pump Energy Index CL	0.91
Net weight	399 lb
Gross weight	514 lb
Shipping volume	21.9 ft³
