This in-line pump has a 2-inch suction and 2-inch discharge connection. The unit includes a 6.15-inch nominal impeller diameter and uses stainless steel construction for the casing, impeller, and shaft, combined with a bronze wear ring. The internal assembly has a replaceable bearing cartridge that isolates the bearings from system fluid temperatures, while the unit supports temperatures up to 250°F. The fluid path includes a mechanical seal assembly consisting of a ceramic seat, carbon mating ring, and EPT elastomers. This standardized cartridge and seal arrangement simplifies maintenance requirements for the system.
This 56-frame assembly accommodates 1 1/2 and 2 HP motors, though the unit is configured as a pump less motor. Maintenance-free operation is supported by permanently sealed, grease-lubricated motor ball bearings. Utilizing a rear pull-out design, the assembly permits complete removal of the motor and rotating components for servicing without disturbing the connected piping layout.
