Taco PSDG120100-1A PSA Suction Diffuser, 12" x 10", Grooved

SKU: LSIDMPZFDK Part Number: PSDG120100-1A Model: PSDG

Price:
Sale price$14,081.95 Regular price$23,470.00

Save 40% Call 844-448-0880 for large volume pricing

Stock:
Call or Chat for availability
 More payment options

Description

This Taco PSD Specialty Suction Diffuser provides economical and compact pump protection by straining foreign particles and providing proper flow conditions to the pump. It is designed to mount directly to the suction side of a pump in either a horizontal or vertical position. With a size of 12" x 10", this suction diffuser is ideal for use in commercial and industrial applications where high flow rates and pressure levels are required.

Features & Benefits

  • Compact design enables the unit to act as an elbow, strainer, and entry pipe to the suction side of the pump, reducing installation time, overall cost, and joint leak paths.
  • Equal-size flanges or reduced outlet flange sizes are available. Reduced outlet design eliminates the need for a reducing base elbow.
  • Quick opening knobs allow for quick maintenance.
  • O-ring seal eliminates the need to clean the sealing area and install a new flat gasket in competitive models.
  • Straightening vanes on the suction diffuser's outlet side reduce turbulence into the pump. This minimizes stress and erosion within the pump and eliminates the need for a length of straight pipe to diminish turbulence.
  • Robust 5-to-1 Open Area Ratio and blow-off feature extend the time between servicing and allow easy draining and flushing.
  • A separate removable fine mesh screen liner is installed in each diffuser for start-up. After the start-up period, remove and discard, leaving the primary screen for operation.
  • Special pads fit the inside diameter of standard pipe, eliminating the need for pipe saddles and relieving stress on hanger systems.
  • Gauge tapping is available as specified.

Specifications

Manufacturer Taco
Part Number PSDG120100-1A
Model PSDG
Connection Size 12" x 10"
Connection Type Grooved

About Taco

Taco Comfort Solutions is a manufacturer of high-quality, high-efficiency heating, cooling, and plumbing products. With 100 years of experience using water as a heat transfer medium, Taco's expertise helps save energy, money, and resources.
