Description
This submersible pump is designed for renewable energy applications, utilizing a built-in inverter compatible with solar, wind, and AC power sources. It operates on both AC and DC voltage and is suitable for medium heads and flow rates. The system offers flexibility in energy supply with features like maximum power point tracking (MPPT), dry-running protection, voltage regulation, and overload protection. It can be adapted to various installation needs in water treatment fertigation, chemigation & dosing, controls & digital groundwater management, as well as drip irrigation systems.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 95027334 |
| Stages | 2 |
| Approvals | CE,EAC,CN RoHS Exempt |
| Pump Number | 95027413 |
| Return valve | Y |
| Zinc Anodes | No |
| Pump | Stainless steel, DIN W.-Nr. 1.4301, AISI 304 |
| Impeller | EN 1.4301 |
| Motor | Stainless steel, DIN W.-Nr. 1.4301, AISI 304 |
| Rotor | Stainless steel, DIN W.-Nr. 1.4301, AISI 304 |
| Stator | Stainless steel / EPDM, DIN W.-Nr. 1.4301, AISI 304 |
| Maximum ambient pressure | 217.56 psi |
| Maximum operating pressure | 217.56 psi |
| Type of connection | NPT(M) |
| Size of connection | 1 inch |
| Minimum borehole diameter | 2.99 in |
| Pumped liquid | Water |
| Liquid temperature range | 32 .. 104 °F |
| Selected liquid temperature | 68 °F |
| Density | 62.29 lb/ft³ |
| Motor type | MSF3 |
| Power input - P1 | 1.4 kW |
| Rated power - P2 | 1.34 HP |
| Rated voltage AC | 1 x 90-240 V |
| Rated voltage DC | 30-300 V |
| Rated current | 8.4 A |
| Power factor | 1.0 |
| Rated speed | 3600 rpm |
| Start. method | direct-on-line |
| Enclosure class (IEC 34-5) | IP68 |
| Insulation class (IEC 85) | F |
| Built-in motor protection | Y |
| Thermal protec | internal |
| Length of cable | 6.56 ft |
| Udc | 300 V, 30 V |
| Minimum efficiency index, MEI ≥ | -.-- |
| Net weight | 17.4 lb |
| Gross weight | 21.4 lb |
| Shipping volume | 0.85 ft³ |
| Sales region | North America |
| Country of origin | MX |
| Custom tariff no. | 8413.70.2004 |
