Description
This horizontal multistage end-suction pump is categorized under inline multi stage pumps.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 97681710 |
| Rated pump speed | 3525 rpm |
| Rated flow | 337 US gpm |
| Rated head | 283.8 ft |
| Maximum head | 365.5 ft |
| Stages | 3 |
| Impellers | 3 |
| Number of reduced-diameter impellers | 1 |
| Low NPSH | N |
| Pump orientation | Horizontal |
| End suction pump (Yes/No) | Y |
| Shaft seal arrangement | Single |
| Code for shaft seal | HQQE |
| Approvals on nameplate | CE,NSF/ANSI 61 |
| Curve tolerance | ISO9906:2012 3B |
| Pump version | H |
| Base | Cast iron, EN 1563 EN-GJS-500-7, ASTM A536 80-55-06 |
| Impeller | Stainless steel, EN 1.4301, AISI 304 |
| Material code | A |
| Code for rubber | E |
| Bearing | SIC |
| Support bearing | Graflon |
| Maximum operating pressure | 232.06 psi |
| Max pressure at stated temperature | 232 psi / 250 °F, 232 psi / -22 °F |
| Size of suction port | 4 inch |
| Size of outlet port | 3 inch |
| Pressure rating for connection | PN 16 |
| Flange rating inlet | 150 lb |
| Flange size for motor | 324TC |
| Connect code | G40 |
| Pumped liquid | Water |
| Liquid temperature range | -22 .. 248 °F |
| Selected liquid temperature | 68 °F |
| Density | 62.29 lb/ft³ |
| Motor standard | NEMA |
| Frequency converter | None |
| Pressure sensor | N |
| Net weight | 234 lb |
| Gross weight | 422 lb |
| Shipping volume | 28.3 ft³ |
| Sales region | USA |
