Grundfos 59896124, UP15-18BUC7 Circulator Pump 1/25hp 115V

SKU: LSIIYWLF3Z Part Number: 59896124

Price:
Sale price$432.95 Regular price$472.00

Save 8% Call 844-448-0880 for large volume pricing

Stock:
In stock (3 units), ready to be shipped
 More payment options

Description

This circulator pump is designed for domestic hot water recirculation and underfloor heating systems. It has a bronze pump housing suitable for drinking water applications, operates at 115V with a frequency of 60Hz, and includes a 3/4" connection size.

Specifications

Manufacturer Grundfos
Part Number 59896124
Speed Number 1
Rated flow 7.97 US gpm
Max flow 14.5 US gpm
Rated head 8.327 ft
Maximum head 14.44 ft
Approvals UL, CSA
Pump with built-in isolating and non-return valves Yes
Pump housing Bronze, CuZn16Si4-C, ASTM B584 C87500
Impeller Composite, PES+30% GF
Maximum ambient temperature 104 °F
Ambient max at 176°F liquid 176 °F
Maximum operating pressure 145.04 psi
Type of connection 3/4" SWEAT, Bronze Sweat
Pipe connection 3/4" SWEAT
Pressure rating for connection PN 10
Port-to-port length 6 3/4 in
Pumped liquid Water
Liquid temperature range 35.6 .. 230 °F
Selected liquid temperature 140 °F
Density 61.35 lb/ft³
Max. power input 85 W
Main frequency 60 Hz
Rated voltage 1 x 115 V
Current in speed 3 0.74 A
Capacitor size - run 10 µF
Number of poles 2
Insulation class (IEC 85) F
Built-in motor protection CONTACT
Thermal protec Impedance protected
Terminal box position 9H
Net weight 5.32 lb
Gross weight 5.84 lb
Country of origin US
Custom tariff no. 8413.70.2005

About Grundfos

Grundfos has a wide range of products, pump solutions, and services for all applications. Grundfos' energy-efficient pumps provide comfort and move water, wastewater, and industrial liquids all over the world.
