Description
This vertical multistage centrifugal pump has suction and discharge ports on the same level.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 98056373 |
| Rated pump speed | 3461 rpm |
| Rated flow | 90.3 US gpm |
| Rated head | 152.9 ft |
| Maximum head | 200.5 ft |
| Actual impeller diameter | 4.13 in |
| Stages | 3 |
| Impellers | 3 |
| Number of reduced-diameter impellers | 0 |
| Low NPSH | N |
| Pump orientation | Vertical |
| Shaft seal arrangement | Single |
| Code for shaft seal | HQQE |
| Approvals | CE,CURUS |
| Approvals for drinking water | NSF/ANSI 61 |
| Curve tolerance | ISO9906:2012 3B |
| Pump version | P |
| Base | Cast iron, EN 1561 EN-GJL-200, ASTM A48-25B |
| Impeller | Stainless steel, EN 1.4301, AISI 304 |
| Material code | A |
| Code for rubber | E |
| Maximum ambient temperature | 140 °F |
| Maximum operating pressure | 145.04 psi |
| Max pressure at stated temperature | 145 psi / 250 °F, 145 psi / -4 °F |
| Type of connection | Oval / NPT(F) |
| Size of suction port | 2 inch |
| Size of outlet port | 2 inch |
| Pressure rating for connection | PN 10 |
| Flange size for motor | 182TC |
| Connect code | B |
| Pumped liquid | Water |
| Liquid temperature range | -4 .. 248 °F |
| Selected liquid temperature | 68 °F |
| Density | 62.29 lb/ft³ |
| Motor standard | NEMA |
| Motor type | 112CA |
| Rated power - P2 | 5 HP |
| Power (P2) required by pump | 5 HP |
| Main frequency | 60 Hz |
| Rated voltage | 3 x 208-230YY/460Y V |
| Service factor | 1.15 |
| Rated current | 14,1-13,1/7,29 A |
| Starting current | 1000-1470 % |
| Cos phi - power factor | 0.89-0.86 |
| Rated speed | 3525-3540 rpm |
| IE Efficiency class | NEMA Premium / IE3 60Hz |
| Motor efficiency at full load | 88.5 % |
| Motor efficiency at 3/4 load | 88.5-87.3 % |
| Motor efficiency at 1/2 load | 86.9-84.7 % |
| Number of poles | 2 |
| Enclosure class (IEC 34-5) | 55 Dust/Jetting |
| Insulation class (IEC 85) | F |
| Built-in motor protection | PTC |
| Frequency converter | None |
| Pressure sensor | N |
| DOE Pump Energy Index CL | 0.91 |
| Net weight | 176 lb |
| Gross weight | 192 lb |
| Shipping volume | 8.26 ft³ |
