This in-line pump has a 2-inch suction and 2-inch discharge, with a 4.90-inch nominal impeller diameter. The casing and bracket consist of cast iron, while the impeller and shaft use stainless steel. It includes a replaceable bearing cartridge assembly that isolates the ball bearings from system fluid temperatures up to 250°F. This unit also includes a mechanical seal assembly built with a ceramic seat, carbon rotor, and EPT elastomers. The standardized cartridge arrangement permits the use of common service components to simplify maintenance requirements across the installation.
The motor is a 1/2 HP, 1750 RPM, ODP unit, configured for a 115/230V, 60Hz, 1PH power supply. Maintenance-free operation is supported by permanently sealed, grease-lubricated motor ball bearings. Utilizing a rear pull-out design, the assembly permits complete removal of the motor and rotating components for servicing without disturbing the connected piping layout.
