Please note this item is made to order and additional lead-times may apply.
This NIBCO lug type butterfly valve provides bi-directional dead-end service without a downstream flange, and bubble-tight shutoff at 232psi to meet today's higher pressure demands. The valve performs well in isolation and throttling applications, commercial, some light industrial process, and a range of chemical applications. This NIBCO ductile iron butterfly valve provides ease of operation with quarter-turn (90 degrees) open to close. The unique EPDM molded-in seat liner with Nylon Coated Ductile Iron disc is recommended for the higher pressure requirements of Commercial HVAC systems today. An extended neck allows for insulation up to 2 inches. Please refer to NIBCO technical data sheets, chemical resistance guides and catalogs for engineering and installation information. Choose NIBCO butterfly valves for the most specified, versatile and economical valve option in commercial, mechanical and industrial applications. NIBCO butterfly valves are backed by the NIBCO 5-year 125% limited warranty.
Features
- Valve pressure rating 232 psi
- EPDM Seat 32°F to 212°F
- Lug style
- EPDM molded-in seat liner
- Ductile Iron - Nylon Coated
- Stainless Steel Stem
- Bronze Bushings
- Extended neck
- Gear Operated
- Not recommended for steam service
- Designed to meet MSS SP-67
- MSS SP-25 (markings)
