Grundfos 96101003, Vertical Multistage Centrifugal Pump CRT4-7

Roll over image to zoom in Click on image to zoom

Grundfos 96101003, Vertical Multistage Centrifugal Pump CRT4-7

Name: Grundfos 96101003, Vertical Multistage Centrifugal Pump CRT4-7
Brand: Grundfos
SKU: LSINK6TQKW
Price: 9542.95 USD
Availability: OutOfStock

SKU: LSINK6TQKW Part Number: 96101003

Price:

$9,542.95 $14,243.00

Save 33% Call 844-448-0880 for large volume pricing

Stock:

Obsolete

Quantity:

This vertical multistage centrifugal pump has suction and discharge ports on the same level. It is constructed with titanium, which provides exceptional resistance to a wide range of acids, alkalis, seawater, and industrial chemicals.

Manufacturer	Grundfos
Part Number	96101003
Pump speed on which pump data is based	3450 rpm
Rated flow	30.8 US gpm
Rated head	223.1 ft
Head max	337.9 ft
Stages	8
Impellers	7
Low NPSH	N
Pump orientation	Vertical
Primary shaft seal	AUUE
Approvals	CE
Curve tolerance	ISO9906:2012 3B
Pump version	A
Pump housing	Titanium, ASTM B 265
Impeller	Titanium, ASTM B 265
Material code	A
Code for rubber	E
Maximum operating pressure	362.59 psi
Max pressure at stated temperature	363 psi / 250 °F, 363 psi / -4 °F
Flange standard	Victaulic
Pipe connection	PJE 1 1/4
Flange size for motor	182TC
Connect code	P
Pumped liquid	Water
Liquid temperature range	-4 .. 248 °F
Selected liquid temperature	68 °F
Density	62.29 lb/ft³
Motor standard	NEMA
Rated power - P2	3 HP
Power (P2) required by pump	3 HP
Number of poles	2
Frequency converter	None
Net weight	37.5 lb
Gross weight	48.5 lb

CR, CRI, CRN, CRT, CRE, CRIE, CRNE, CRTE (Custom-built pumps) (Data booklet)

CR, CRI, CRN, CRT (I & O instructions)

CRT, CRTE (Data booklet)

Grundfos has a wide range of products, pump solutions, and services for all applications. Grundfos' energy-efficient pumps provide comfort and move water, wastewater, and industrial liquids all over the world.
