Grundfos 95027351, 25 SQF-3 Submersible Groundwater Pump, 1.5" NPT

SKU: LSINLOA24L Part Number: 95027351

Price:
Sale price$7,116.95

Call 844-448-0880 for large volume pricing

Stock:
Call or Chat for availability
 More payment options

Description

This submersible pump is designed for renewable energy sources, operating with built-in inverters compatible with solar, wind, and AC power. It supports both AC and DC voltage and is part of a system that provides reliable water supply solutions using flexible energy options. The pump accommodates low heads and large flow rates while offering features like maximum power point tracking, dry-running protection, and overload safeguards.

Specifications

Manufacturer Grundfos
Part Number 95027351
Stages 3
Approvals UKCA,CE,EAC,CN RoHS Exempt,Morocco, Sepro
Pump Number 95027389
Return valve Y
Zinc Anodes No
Pump Stainless steel, DIN W.-Nr. 1.4301, AISI 304
Impeller Stainless steel, EN 1.4301, AISI 304
Motor Stainless steel, DIN W.-Nr. 1.4301, AISI 304
Rotor DIN W.-Nr. 1.4301, AISI 304
Stator DIN W.-Nr. 1.4301, AISI 304
Maximum ambient pressure 217.56 psi
Maximum operating pressure 217.56 psi
Type of connection NPT(M)
Size of connection 1 1/2 inch
Minimum borehole diameter 4.09 in
Pumped liquid Water
Liquid temperature range 32 .. 104 °F
Selected liquid temperature 68 °F
Density 62.29 lb/ft³
Motor type MSF3
Power input - P1 1.4 kW
Rated power - P2 1.34 HP
Rated voltage AC 1 x 90-240 V
Rated voltage DC 30-300 V
Rated current 8.4 A
Power factor 1.0
Rated speed 3600 rpm
Start. method direct-on-line
Enclosure class (IEC 34-5) IP68
Insulation class (IEC 85) F
Built-in motor protection Y
Thermal protec internal
Length of cable 6.56 ft
Udc 300 V, 30 V
Minimum efficiency index, MEI ≥ -.--
Net weight 17.9 lb
Gross weight 21.2 lb
Shipping volume 1 ft³
Sales region North America
Country of origin MX
Custom tariff no. 8413.70.2004

About Grundfos

Grundfos has a wide range of products, pump solutions, and services for all applications. Grundfos' energy-efficient pumps provide comfort and move water, wastewater, and industrial liquids all over the world.
