This in-line pump has a 1 1/2" suction and a 1 1/2" discharge port. The casing, impeller, and face plate use stainless steel construction, while the bracket is cast iron. A stainless steel shaft is paired with a replaceable bearing cartridge assembly that isolates the bearings from system fluid temperatures. The unit includes a mechanical seal assembly with a ceramic seat, carbon rotor, and EPT elastomers, accommodating fluid temperatures up to 250°F. The 6.35" nominal impeller diameter sits within the housing for consistent hydraulic performance.
This unit is supplied less motor and allows for integration with various external power sources. Maintenance-free operation is supported by permanently sealed, grease-lubricated motor ball bearings. With a rear pull-out design, the assembly permits complete removal of the motor and rotating components for servicing without disturbing the connected piping layout.
