This in-line pump has a 2-inch suction and discharge connection. The construction includes a stainless steel casing and impeller, paired with a bronze wear ring for internal clearance control. The assembly houses a stainless steel shaft within a replaceable bearing cartridge containing permanently sealed, grease-lubricated ball bearings. A mechanical seal assembly with a ceramic seat, carbon mating ring, and EPT elastomers manages fluid containment at temperatures up to 250°F. The unit includes standardized cartridge components to simplify routine service requirements while maintaining consistent hydraulic performance.
The 1 HP, 1750 RPM, ODP motor operates on 115/208-230V, 1PH power. Maintenance-free operation is supported by permanently sealed, grease-lubricated motor ball bearings. Utilizing a rear pull-out design, the assembly permits complete removal of the motor and rotating components for servicing without disturbing the connected piping layout.
