Description
This horizontal multistage end-suction pump is engineered for inline applications and optimized for pressure boosting in industrial settings.
Specifications
| Manufacturer | Grundfos |
|---|---|
| Part Number | 97657369 |
| Rated pump speed | 3439 rpm |
| Rated flow | 15.4 US gpm |
| Rated head | 111.9 ft |
| Maximum head | 154.5 ft |
| Stages | 5 |
| Impellers | 5 |
| Number of reduced-diameter impellers | 0 |
| Low NPSH | N |
| Pump orientation | Horizontal |
| End suction pump (Yes/No) | Y |
| Shaft seal arrangement | Single |
| Code for shaft seal | HQQE |
| Approvals on nameplate | CURUS,NSF/ANSI 61 |
| Curve tolerance | ISO9906:2012 3B |
| Pump version | H |
| Cooling | TEFC |
| Base | Cast iron, EN 1561 EN-GJL-200, ASTM A48-25B |
| Impeller | Stainless steel, EN 1.4301, AISI 304 |
| Material code | A |
| Code for rubber | E |
| Bearing | SIC |
| Maximum ambient temperature | 140 °F |
| Maximum operating pressure | 232.06 psi |
| Max pressure at stated temperature | 232 psi / 250 °F, 232 psi / -4 °F |
| Size of suction port | 1 1/2 inch |
| Size of outlet port | 1 inch |
| Pressure rating for connection | PN 16 |
| Flange rating inlet | 150 lb |
| Flange size for motor | 56C |
| Connect code | GA |
| Pumped liquid | Water |
| Liquid temperature range | -4 .. 248 °F |
| Selected liquid temperature | 68 °F |
| Density | 62.29 lb/ft³ |
| Motor standard | NEMA |
| Motor type | 71BA |
| Rated power - P2 | 0.75 HP |
| Power (P2) required by pump | 0.75 HP |
| Main frequency | 60 Hz |
| Rated voltage | 3 x 208-230YY/460Y V |
| Service factor | 1.25 |
| Rated current | 2.40-2.30/1.20 A |
| Starting current | 590-650 % |
| Cos phi - power factor | 0.84-0.78 |
| Rated speed | 3430-3460 rpm |
| IE Efficiency class | NEMA Premium / IE3 60Hz |
| Motor efficiency at full load | 78.9-80.1 % |
| Motor efficiency at 3/4 load | 79.9-79.3 % |
| Motor efficiency at 1/2 load | 77.3-75.2 % |
| Number of poles | 2 |
| Enclosure class (IEC 34-5) | 55 Dust/Jetting |
| Insulation class (IEC 85) | F |
| Built-in motor protection | NONE |
| Frequency converter | None |
| Pressure sensor | N |
| Net weight | 60.7 lb |
| Gross weight | 73 lb |
| Shipping volume | 4.94 ft³ |
| Sales region | USA |
