This Taco CI Series close-coupled end suction pump features an 8" suction connection and a 6" discharge connection with ANSI Class 125 flanges. The pump construction includes a cast iron casing, an 11" nominal diameter bronze impeller, and a stainless steel shaft sleeve. It utilizes a mechanical seal with a ceramic seat, carbon rotor, and EPT rubber. The design incorporates a slip-on shaft sleeve, flush seal line taps, and pressure tappings on the suction and discharge connections. The pump uses a rear pullout design and a top center line discharge to facilitate maintenance and piping alignment.
This unit is configured with a 50 HP, 1750 RPM motor in a 326JM frame style with feet. The Baldor motor features an ODP enclosure and operates on a 230/460V, 3PH, 60Hz power supply with across the line starting. It meets premium efficiency standards and includes AEGIS shaft grounding. The pump operates at a 40°C ambient temperature and handles fluid temperatures up to 250°F with CCW rotation. The unit has a DOE PEI rating of 0.92.
