This Taco FI Series base-mounted end suction pump features a 5" suction and 4" discharge with ANSI Class 125 flanges. The pump is constructed with a cast iron casing and a 9-1/2" nominal diameter bronze impeller. It uses a stainless steel shaft paired with a replaceable bronze shaft sleeve in a dry shaft design. The mechanical seal consists of a ceramic seat, carbon rotor, and EPT rubber, rated for temperatures up to 250°F. The casing includes integrated pressure tappings on the suction and discharge connections.
This unit operates at 1750 RPM and is driven by a 15 HP Baldor Super E premium efficiency motor with a TEFC enclosure and a 254 NEMA frame. The electrical configuration is 230/460V, 3PH, 60Hz, supporting across-the-line starting. It includes AEGIS shaft grounding and is rated for a 40°C ambient environment. The pump is mounted on a welded base with an integrated drip pan and utilizes a Woods coupler protected by a coupler guard. This model is EISA compliant with a DOE PEI of 0.93 and an HI energy rating of 7.
