This Taco FI Series base-mounted end suction pump features a 10" suction and 8" discharge with ANSI Class 125 flanges. The unit includes a cast iron casing, a 13-1/2" nominal diameter bronze impeller, a stainless steel shaft, and a replaceable bronze shaft sleeve. It incorporates a bronze wear ring and a mechanical seal with a ceramic seat, carbon rotor, and EPT rubber, rated for operation at temperatures up to 250°F. The bearing frame utilizes greaseable bearings.
This unit operates at 1750 RPM and uses a 125 HP ODP motor in a NEMA 405T frame. It is configured for a 460/60/3 power supply with an across-the-line starting option. The assembly includes a premium efficiency Baldor motor that meets MG1-12.55 standards and incorporates an AEGIS SGR with an insulated bearing on the non-drive end. The pump is mounted on a welded base with an integrated drip pan and a standard coupler guard. This equipment has a DOE PEI rating of 0.94.
