This in-line pump uses 2-inch flanged connections with stainless steel construction for the casing, impeller, and shaft. The unit includes a replaceable bearing cartridge assembly that isolates the ball bearings from system fluid temperatures. The pump is equipped with a mechanical seal assembly consisting of a ceramic seat, carbon mating ring, and EPT elastomers. This cooler-running bearing cartridge construction simplifies maintenance, as the standardized geometry allows common service components across the unit.
The pump operates with a 3/4 HP, 1750 RPM, ODP motor using 3PH power. Maintenance-free operation is supported by permanently sealed, grease-lubricated motor ball bearings. Utilizing a rear pull-out design, the assembly permits complete removal of the motor and rotating components for servicing without disturbing the connected piping layout.
