This Taco Shell & Tube Heat Exchanger, model G6404S, is designed with a nominal shell diameter of 6 inches. It features four tube passes and a tube bundle length of 24 inches. The tubes are made of copper and have a size of 3/4 OD x .035 (20 Ga) wall SB75. This heat exchanger is specifically designed for steam to liquid heat transfer applications. It is equipped with channel-flanged connections without a cover. The tube plate is made of steel, ensuring durability and reliability. The separators are also made of steel. This heat exchanger has a working pressure rating of 150 psi, making it suitable for various industrial applications.
Taco Shell & Tube Heat Exchangers Overview
Taco Shell & Tube Heat Exchangers are equipment used in HVAC systems and various industrial applications for the purpose of transferring heat between two fluids. These exchangers are composed of a large outer shell and an inner tube bundle. The arrangement allows one fluid to flow through the tubes while a second fluid circulates outside the tubes but within the shell. As they pass each other, heat exchange occurs, with the fluid inside the tubes either gaining or losing heat from the fluid in the shell. Taco Shell & Tube Heat Exchangers are noted for their durable construction, effectiveness in heat transfer, and ease of maintenance, including the straightforward process of replacing the tube bundle.
Note: product image is generic
