This Taco Shell & Tube Heat Exchanger, model G8408S, is designed with a nominal shell diameter of 8 inches. It features 4 tube passes and a tube bundle length of 48 inches. The tubes are made of copper, with a size of 3/4 OD x .035 (20 Ga) wall SB75. This heat exchanger is specifically designed for steam to liquid heat transfer applications. It utilizes a channel-flanged connection type without a cover. The tube plate material is steel, while the separators are also made of steel. With a working pressure of 150 psi, this heat exchanger is capable of efficiently transferring heat between steam and liquid mediums.
Taco Shell & Tube Heat Exchangers Overview
Taco Shell & Tube Heat Exchangers are equipment used in HVAC systems and various industrial applications for the purpose of transferring heat between two fluids. These exchangers are composed of a large outer shell and an inner tube bundle. The arrangement allows one fluid to flow through the tubes while a second fluid circulates outside the tubes but within the shell. As they pass each other, heat exchange occurs, with the fluid inside the tubes either gaining or losing heat from the fluid in the shell. Taco Shell & Tube Heat Exchangers are noted for their durable construction, effectiveness in heat transfer, and ease of maintenance, including the straightforward process of replacing the tube bundle.
Note: product image is generic
