This Taco Shell & Tube Heat Exchanger, model G16416S, is a reliable and efficient heat transfer solution. With a nominal shell diameter of 16 inches, it provides ample capacity for various applications. The heat exchanger features 4 tube passes, ensuring optimal heat transfer efficiency. The tube bundle length measures 96 inches, allowing for increased surface area and enhanced performance. The tubes are made of copper with a size of 3/4 OD x .035 (20 Ga) wall SB75, ensuring excellent heat conductivity. This heat exchanger is designed to transfer heat between steam and liquid mediums. It is equipped with a channel-flanged connection type without a cover, providing easy access for maintenance and inspection. The tube plate material is steel, ensuring durability and longevity. Additionally, the separators are also made of steel, further enhancing the overall strength of the heat exchanger. With a working pressure of 150 psi, this Taco Shell & Tube Heat Exchanger delivers reliable performance in demanding environments.
Taco Shell & Tube Heat Exchangers Overview
Taco Shell & Tube Heat Exchangers are equipment used in HVAC systems and various industrial applications for the purpose of transferring heat between two fluids. These exchangers are composed of a large outer shell and an inner tube bundle. The arrangement allows one fluid to flow through the tubes while a second fluid circulates outside the tubes but within the shell. As they pass each other, heat exchange occurs, with the fluid inside the tubes either gaining or losing heat from the fluid in the shell. Taco Shell & Tube Heat Exchangers are noted for their durable construction, effectiveness in heat transfer, and ease of maintenance, including the straightforward process of replacing the tube bundle.
